| Booster Model | 2RB10 | 2RB12 | 2RB15 | 2RB20 | 3RB25 | 3RB30 | |
| Max Working Pressure | KG/CM2 | 35 | 35 | 35 | 35 | 35 | 35 |
| Free air Delivery @ 115 PSI Input @425 PSI Input |
CFM | 60 | 80 | 96 | 123 | 160 | 180 |
| Free air Delivery @ 115 PSI Input @425 PSI Input |
CFM | 80 | 100 | 118 | 154 | 200 | 225 |
| Number of Cylinders | NO | 2 | 2 | 2/3 | 2/3 | 3 | 3 |
| Rated Motor Power | HP | 10 | 12.5 | 15 | 20 | 25 | 30 |
| Driven System | Belt / Pulley | ||||||
| Air Outlet Connection | 1" | 1" | 1.1/2" | 1.1/2" | 2" | 2" | |
| Tank Capacity | LTR. | 300 | 300 | 500 | 500 | 500 | 500 |
