REAL’S Vacuum Pumps are the number one choice for demanding applications, providing top operating efficiency combined with low maintenance. And best of all, these vacuum pumps are backed by REAL AIR COMPRESSOR, the world’s leader in Air compressor and pump manufacturing.

Features

Separately cast cylinders with deep fins for improved cooling and efficiency

100% cast iron frame and cylinders for durability and long life

Easily accessible stainless steel valve and one piece connecting rod improves serviceability and reduces cost of maintenance

Low oil level switch standard on all packages to prevent compressor from potential damages due to low oil level.

Specification

MODEL	MOTOR		Bore X Stroke (INCH)	No. of CYLINDER	Vacuum (Hg)		Piston Displacement
MODEL	H.P.	K.W.	Bore X Stroke (INCH)	No. of CYLINDER	Inch	Mm	Cfm	Ltr/min
V240	1.5	1.10	3" & 3" X 2.75"	2	29.00	736.6	21.60	610
VT240	1.5	1.10	3" & 3" X 2.75"	2	29.60	751.8	10.80	305
V249	2.0	1.50	4" & 4" X 2.75"	2	29.00	736.6	34.60	980
VT249	2.0	1.50	4" & 4" X 2.75"	2	29.65	753.1	17.30	490
V260	5.0	3.70	5" & 5" X 3.5"	2	29.00	736.6	60.00	1699
VT260	5.0	3.70	5" & 5" X 3.5"	2	29.70	754.4	30.00	849
V12	7.5	5.50	5.5" & 5.5" X 4"	2	29.00	736.6	110.00	3114
VT12	7.5	5.50	5.5" & 5.5" X 4"	2	29.65	753.1	55.00	1557
V20	10.0	7.50	5.5" & 5.5" & 5.5" X 4"	3	29.20	741.7	149.60	4235
VT20	10.0	7.50	5.5" & 5.5" & 5.5" X 4"	3	29.65	753.1	99.00	2803
